SYS1-DM1A

SYS1-DM1A is based on magnetostrictive waveguide technology and adopts non-contact measurement principle to achieve ±0.05% FS high-precision displacement detection. Its performance parameters are fully comparable to those of internationally renowned brands. The product is equipped with an industrial-grade four-pin socket interface, supports 4-20mA/0-10V analog and RS485 communication (MODBUS-RTU protocol) output, and is compatible with mainstream automation control systems. It adopts high-protection packaging technology and can operate stably in a wide temperature range of -30℃ to +75℃. The IP67 protection level effectively resists vibration shock and dust erosion. The ultra-long cycle life design of 50 million times meets the needs of high-frequency dynamic measurement. It is widely used in hydraulic machinery, precision transmission devices, rail transportation equipment, medical imaging equipment and other fields, providing a highly reliable and easy-to-install domestic alternative for industrial displacement monitoring.
